Remote Commands
R&S
®
FSW
1245User Manual 1173.9411.02 ─ 43
Gui setting Description Remote command
"User Defined Colors" Selects the user-defined color setting.
HCOP:CMAP:DEF3
"Screen Colors
(Screenshot)"
Selects the current screen colors without any
changes for a screenshot.
HCOP:CMAP:DEF4
HCOPy:CMAP<it>:HSL <hue>, <sat>, <lum>
This command selects the color for various screen elements in print jobs.
Suffix:
<it>
.
Selects the item for which the color scheme is to be defined.
For more information see Chapter 14.10.5.3, "CMAP Suffix
Assignment", on page 1294.
Parameters:
<hue> hue
tint
Range: 0 to 1
<sat> sat
saturation
Range: 0 to 1
<lum> lum
brightness
Range: 0 to 1
Example:
HCOP:CMAP2:HSL 0.3,0.8,1.0
Changes the grid color
Manual operation: See "Defining User-specific Colors" on page 671
HCOPy:CMAP<it>:PDEFined <Color>
This command selects a predefined color for various screen elements in print jobs.
Suffix:
<it>
.
1..n
Selects the item for which the color scheme is to be defined.
For more information see Chapter 14.10.5.3, "CMAP Suffix
Assignment", on page 1294.
Parameters:
<Color> BLACk | BLUE | BROWn | GREen | CYAN | RED | MAGenta |
YELLow | WHITe | DGRay | LGRay | LBLue | LGReen | LCYan |
LRED | LMAGenta
Example:
HCOP:CMAP2:PDEF GRE
Manual operation: See "Predefined Colors" on page 670
Managing Settings and Results
