HCOPy
Selects all measurement results displayed on the screen for the
current channel (or "MultiView"): diagrams, traces, markers,
marker lists, limit lines, etc., including the channel bar and status
bar, for printout on a single page. Displayed items belonging to
the software user interface (e.g. softkeys) are not included. The
size and position of the elements in the printout is identical to the
screen display.
*RST: HCOPy
Example:
HCOP:DEST1 'SYST:COMM:CLIP'
HCOP:CONT WIND
HCOP:DEST1?
//Result: 'MMEM'
HCOP:DEV:LANG1?
//Result: 'PDF'
"Print to clipboard" is automatically switched to "print to PDF file"
when the contents are switched to "multiple windows".
Manual operation: See "Print Screenshot" on page 641
See "Print Multiple Windows" on page 642
HCOPy:CMAP<it>:DEFault<ci>
This command defines the color scheme for print jobs.
For details see "Print Colors" on page 668.
Suffix:
<it>
.
Selects the item for which the color scheme is to be defined.
For more information see Chapter 14.10.5.3, "CMAP Suffix
Assignment", on page 1294.
<ci> See table below
Example:
HCOP:CMAP:DEF2
Selects the optimized color set for the color settings of a print-
out.
Manual operation: See "Print Colors" on page 668
Gui setting Description Remote command
"Screen Colors (Print)" Selects the current screen colors for the
printout. The background is always printed in
white and the grid in black.
HCOP:CMAP:DEF1
"Optimized Colors" Selects an optimized color setting for the
printout to improve the visibility of the colors
(default setting). Trace 1 is blue, trace 2
black, trace 3 green, and the markers are
turquoise. The background is always printed
in white and the grid in black.
HCOP:CMAP:DEF2
Managing Settings and Results
