Remote Commands

R&S

FSW

1269User Manual 1173.9411.02 ─ 43

[SENSe:]CORRection:TRANsducer:COMMent <Comment>

This command defines the comment for the selected transducer factor.

Before you can use the command, you have to select and turn on a transducer.

Parameters:

<Comment> *RST: (empty comment)

Manual operation: See "Comment" on page 681

[SENSe:]CORRection:TRANsducer:DATA {<Frequency>, <Level>}...

This command configures transducer factors for specific trace points. A set of trans-

ducer factors defines an interpolated transducer line and can be stored on the instru-

ment.

For details see Chapter 12.3.1, "Basics on Transducer Factors", on page 675.

Parameters:

<Frequency> The unit for <Frequency> is Hz, which may or may not be omit-

ted. Frequencies have to be sorted in ascending order.

Default unit: Hz

<Level> The unit for <Level> depends on[SENSe:]CORRection:

TRANsducer:UNIT .

Example:

SENSe1:CORRection:TRANsducer:UNIT 'DB'

// Frequency Span 0 Hz to 4 Ghz

SENSe1:CORRection:TRANsducer:DATA 0,8,2GHz,5,4GHz,3

Creates the transducer points:

Manual operation: See "Data Points" on page 682

Frequency Level

0 Hz 8 dB

2 GHz 5 dB

4 GHz 3 dB

[SENSe:]CORRection:TRANsducer:DELete

This command deletes the currently selected transducer factor.

Before you can use the command, you have to select a transducer.

Example:

CORR:TRAN:DEL

Manual operation: See "Delete Line" on page 680

[SENSe:]CORRection:TRANsducer:SCALing <ScalingType>

This command selects the frequency scaling of the transducer factor.

Configuring the R&S

FSW
