Remote Commands
R&S
®
FSW
1281User Manual 1173.9411.02 ─ 43
[SENSe:]CORRection:FRESponse<si>:USER:SLISt<sli>:DATA:
FREQuency<spi>?
[SENSe:]CORRection:FRESponse<si>:USER:SLISt<sli>:DATA:MAGNitude<spi>?
[SENSe:]CORRection:FRESponse<si>:USER:SLISt<sli>:DATA:PHASe<spi>?
Queries the trace values for the specified .snp file and ports.
Suffix:
<si>
.
1..n
irrelevant
<sli> 1..n
Index in Touchstone file list
Use [SENSe:]CORRection:FRESponse<si>:USER:
SLISt<sli>:SIZE? to determine the maximum index number.
<spi> 1..4
S-port pair index, where:
1 = From port - from port
2 = To port - from port
3 = From port - to port
4 = To port - to port
Example:
SENS:CORR:FRES:USER:SLIS2:SEL 'FRes21.s2p'
SENS:CORR:FRES:USER:SLIS2:PORT:TO 2
SENS:CORR:FRES:USER:SLIS2:PORT:FROM 1
SENS:CORR:FRES:USER:SLIS2:DATA:PHAS3?
The correction data from port 1 to port 2 is returned.
Usage: Query only
Manual operation: See "Selected File" on page 696
[SENSe:]CORRection:FRESponse<si>:BASeband:USER:SLISt<sli>:INSert
<FilePath>
[SENSe:]CORRection:FRESponse<si>:INPut<ip>:USER:SLISt<sli>:INSert
<FilePath>
[SENSe:]CORRection:FRESponse<si>:USER:SLISt<sli>:INSert <FilePath>
Loads a new Touchstone file for the current configuration. The maximum number of
files per configuration is 15. The new file is added below the entry specified by the
<sli> index. All other entries with a higher suffix are moved down by one position.
To change the order of the files, use the [SENSe:]CORRection:FRESponse<si>:
USER:SLISt<sli>:MOVE command.
To determine which files are available, use [SENSe:]CORRection:
FRESponse<si>:USER:SLISt<sli>:CATalog? on page 1280.
Suffix:
<si>
.
1..n
irrelevant
