In addition to the predefined settings, a user-defined color set can be configured (see

"Defining User-specific Colors" on page 671).

If "Show Print Colors on Display" is activated, the currently selected print colors are

displayed as a preview for your selection.

Gui setting Description Remote command

"Optimized Colors" Selects an optimized color setting for the

printout to improve the visibility of the colors

(default setting). Trace 1 is blue, trace 2

black, trace 3 green, and the markers are

turquoise. The background is always printed

in white and the grid in black.

HCOP:CMAP:DEF2

"Screen Colors (Print)" Selects the current screen colors for the

printout. The background is always printed in

white and the grid in black.

HCOP:CMAP:DEF1

"Screen Colors

(Screenshot)"

Selects the current screen colors without any

changes for a screenshot.

HCOP:CMAP:DEF4

"User Defined Colors" Selects the user-defined color setting.

HCOP:CMAP:DEF3

Remote command:

HCOPy:CMAP<it>:DEFault<ci> on page 1244

Showing Print Colors on Display

Temporarily shows the currently selected print colors on the screen display. This func-

tion can be used as a preview for printing.

Modifying User-Defined Color Assignments

You can configure the colors used to display and print individual screen objects accord-

ing to your specific requirements.

The colors are configured in the (identical) "Screen Color Setup"/"Printer Color Setup"

dialog boxes.

Display Settings
