Network and Remote Operation
R&S
®
FSW
794User Manual 1173.9411.02 ─ 43
Current LXI Configuration
Displays the current LXI information from the R&S FSW (read-only).
"Current ver-
sion"
Current LXI version
"LXI Extended
Features"
Detected LXI features, such as HiSlip (see "HiSLIP Protocol"
on page 733)
"Computer
name"
Name of the R&S FSW as defined in the operating system (see also
"Computer Name" on page 785)
"MAC address"
Media Access Control address (MAC address), a unique identifier for
the network card in the R&S FSW
"IP address"
IP address of the R&S FSW as defined in the operating system (see
also "IP Address" on page 786).
"ICMP"
Indicates whether the ping responder is active or not
"VXI-11 Dis-
covery"
If enabled, connected devices are detected automatically using the
VXI-11 protocol (see "VXI-11 Protocol" on page 733)
Remote command:
SYSTem:LXI:INFO on page 1298
LXI Password
Password for LAN configuration. The default password is LxiWebIfc.
Remote command:
SYSTem:LXI:PASSword on page 1299
LXI Manufacturer Description
Instrument description of the R&S FSW
Remote command:
SYSTem:LXI:MDEScription on page 1299
LAN Reset
Resets the LAN configuration to its default settings (LCI function).
According to the LXI standard, an LCI must set the following parameters to a default
state.
Parameter Value
TCP/IP Mode DHCP + Auto IP Address
Dynamic DNS Enabled
ICMP Ping Enabled
Password for LAN configuration LxiWebIfc
The LAN settings are configured in the "Network" tab of the "Network + Remote" dialog
box or using the instrument's LXI Browser interface.
Remote command:
SYSTem:LXI:LANReset on page 1298
