Remote Commands
R&S
®
FSW
842User Manual 1173.9411.02 ─ 43
Selecting the Reference Channel......................................................................... 850
Checking Limits.....................................................................................................851
General ACLR Measurement Settings..................................................................858
Configuring MSR ACLR Measurements............................................................... 858
Performing an ACLR Measurement......................................................................888
Retrieving and Analyzing Measurement Results.................................................. 888
Programming Examples for Channel Power Measurements................................ 891
14.5.3.1 Managing Measurement Configurations
The following commands control measurement configurations for ACLR measure-
ments.
CALCulate<n>:MARKer<m>:FUNCtion:POWer<sb>:PRESet............................................. 842
CALCulate<n>:MARKer<m>:FUNCtion:POWer<sb>:STANdard:CATalog?........................... 842
CALCulate<n>:MARKer<m>:FUNCtion:POWer<sb>:STANdard:DELete.............................. 843
CALCulate<n>:MARKer<m>:FUNCtion:POWer<sb>:STANdard:SAVE.................................843
CALCulate<n>:MARKer<m>:FUNCtion:POWer<sb>:PRESet <Standard>
This command loads a measurement configuration.
The measurement configuration for power measurements consists of weighting filter,
channel bandwidth and spacing, resolution and video bandwidth, detector and sweep
time.
If the "Multi-Standard Radio" standard is selected (see "Standard" on page 169), differ-
ent commands are required to configure ACLR measurements (see Chapter 14.5.3.7,
"Configuring MSR ACLR Measurements", on page 858).
Suffix:
<n>
.
Window
<m> Marker
<sb> irrelevant
Parameters:
<Standard> For more information see Chapter 7.2.9, "Reference: Predefined
CP/ACLR Standards", on page 206.
If you want to load a customized configuration, the parameter is
a string containing the file name.
Manual operation: See "Predefined Standards" on page 169
See "User Standards" on page 169
CALCulate<n>:MARKer<m>:FUNCtion:POWer<sb>:STANdard:CATalog?
This command queries all files containing ACLR standards.
Suffix:
<n>
.
Window
<m> Marker
Configuring and Performing Measurements
