R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
858User Manual 1173.9411.02 ─ 43
14.5.3.6 General ACLR Measurement Settings
The following commands control the measurement algorithm.
Useful commands for the ACLR measurement described elsewhere:
●
[SENSe:]POWer:NCORrection on page 1041
●
[SENSe:]POWer:ACHannel:PRESet on page 840
●
[SENSe:]POWer:ACHannel:PRESet:RLEVel on page 841
●
[SENSe:]POWer:TRACe on page 841
●
CALCulate<n>:MARKer<m>:FUNCtion:POWer<sb>:MODE on page 837
Remote commands exclusive to ACLR measurement
[SENSe:]POWer:HSPeed............................................................................................... 858
[SENSe:]POWer:HSPeed <State>
This command turns high speed ACLR and channel power measurements on and off.
If on, the R&S FSW performs a measurement on each channel in the time domain. It
returns to the frequency domain when the measurement is done.
In some telecommunications standards, high speed measurements use weighting fil-
ters with characteristic or steep-edged channel filters for band limitation.
Parameters:
<State> ON | OFF | 1 | 0
*RST: 0
Example:
POW:HSP ON
Manual operation: See "Fast ACLR" on page 172
14.5.3.7 Configuring MSR ACLR Measurements
If the "Multi-Standard Radio" standard is selected (see CALCulate<n>:MARKer<m>:
FUNCtion:POWer<sb>:PRESet on page 842), the channels for the ACLR measure-
ment are configured differently. (For more information see Chapter 7.2.3.4, "Measure-
ment on Multi-Standard Radio (MSR) Signals", on page 162.)
In this case, use the following commands.
● General MSR ACLR Measurement Settings.........................................................858
● MSR Sub Block and Tx Channel Setup................................................................ 859
● MSR Adjacent Channel Setup.............................................................................. 861
● MSR Gap Channel Setup......................................................................................866
● MSR Channel Names........................................................................................... 887
General MSR ACLR Measurement Settings
Useful commands for configuring general MSR ACLR settings described elsewhere:
●
CALCulate<n>:MARKer<m>:FUNCtion:POWer<sb>:PRESet on page 842
Configuring and Performing Measurements
