Ricoh IM 550F

2.Installation
148
16. Release the flat cable and harness from the harness guides.
17. Remove the seven screws from the controller box [A].
• The screw [B] is a tapping screw. Be careful not to use the wrong screws when installing
the controller box.
18. Release the hook [A], and then remove the controller box [B].
