6.Troubleshooting
628
10. Install the filters [A] and [B] in the same way.
11. Insert the fan [A] into the slot with the label facing outward, and then connect the connector and
pass the cables through the harness guides.
12. Install the fans [A] and [B] in the same way.
13. Reattach the covers.
By default, the smell reduction fan (FAN5) stops operating 15 seconds after printing operation finishes.
If further smell reduction is necessary, use SP3-906-001 to configure the time it takes for the fan to
stop.
• SP3-906-001 (Range: 15 - 240 (seconds), default: 15)
Smell issue (IM 550F/600F/P 800/801)
Symptom
The machine sometimes gives off an unpleasant, chemical smell.
