P 800/801
Select one of the Service Program modes (Service, or Engine) with [ / ] keys, and then press the [OK]
key.
Switching Between SP Mode and Copy Mode for Test Printing (IM 550F/600F/600SRF Only)
1. In the SP mode, select the test print. Then press [Copy Window].
2. Use the copy window (copier mode), to select the appropriate settings (paper size, etc.) for the test
print.
3. Press [Start] to start the test print.
4. Press SP Mode (highlighted) to return to the SP mode screen and repeat from step 1.
Selecting the Program Number (IM 550F/600F/600SRF Only)
Program numbers have two or three levels.
1. Refer to the Service Tables to find the SP that you want to adjust before you begin.
2. Press the Group number on the left side SP Mode window that contains the SP that you want to
adjust.
3. Use the scrolling buttons in the center of the SP mode window to show the SP number that you
want to open. Then press that number to expand the list.
4. Use the center touch-panel buttons to scroll to the number and title of the item that you want to set
and press it. The small entry box on the right activates and shows the below default or the current
settings.
Refer to the Service Tables for the range of allowed settings.
5. Do this procedure to enter a setting:
Press to toggle between plus and minus and use the keypad to enter the appropriate
number. The number you enter writes over the previous setting.
Press [#] to enter the setting. (The value is not registered if you enter a number that is out of
range.)
Press [Yes] when you are prompted to complete the selection.
6. If you need to perform a test print, press [Copy Window] to open the copy window and select the
settings for the test print. Press [Start], and then press SP Mode (highlighted) in the copy window to
return to the SP mode display.
7. Press [Exit] two times to return to the copy window when you are finished.
