Ricoh IM 550F

4.Replacement and Adjustment
441
6. Remove the finisher jogger fence HP sensor bracket [A] ( x 1, x 1, hooks).
Finisher Jogger Motor (M16)
1. Remove the finisher frames. (Finisher Frames)
2. Remove the finisher transport motor (M12). (Finisher Transport Motor (M12))
3. Remove the finisher jogger fence HP sensor bracket (Finisher Jogger Fence HP Sensor (S24))
4. Remove the two screws.
5. Remove the finisher jogger motor bracket [A] ( x 1, x 2)
