8.Smart Operation Panel G2.5
719
[B]: PET film
[C]: Transparent conductive film
[D]: Base glass
[E]: LCD panel
Self-Check (multi-touch calibration) mechanism
With the Multi-touch calibration in the self-check function, the touch panel is automatically calibrated
using the results of touches to the top left and bottom right positions.
The values of “EVR_X”, “EVR_Y”, “X_MAX”, and “Y_MAX” are used for internal processing. They do
not indicate the positions or distance of the touched points. There is no problem unless there is a huge
difference between the values of the first calibration and the second calibration.
Controlling the Power Supply
Exiting Energy Saving Modes
Because this model of Smart Operation Panel has no hardware keys, the MFP exits from energy saving
mode when the user does one of the following:
• Touches the display panel
• Lifts the ADF
• Sets an original in the ADF
Screen Startup Mode
Startup Modes
There are two screen startup modes. The factory default setting is Normal.
1. Normal
This is the standard startup mode. When the main power of the MFP is turned ON, the control
panel starts up using less power compared to Quick mode.
2. Quick
By preparing for the next startup when the machine shuts down, the control panel starts up faster
than in Normal mode.
Changing the Screen Startup Mode
Screen Startup Mode can be changed in Screen Features Settings.
