Ricoh IM 550F

4.Replacement and Adjustment
265
3. Release the hook and remove the rear right stay [A].
• Be careful not to damage the hooks on the inside of the rear right stay when you remove or
install the rear right stay.
Rear Right Stay (IM 550F/600F)
1. Remove the controller cover. (Controller Cover (IM550F/600F))
2. Insert a flathead screwdriver in the order of , , and to release three hooks of the rear right
stay [A].
