Ricoh IM 550F

6.Troubleshooting
611
Abbreviation
Name
Abbreviation
Name
PFFS3
Paper feed sensor 3
*1
PLS
Paper feed tray limit sensor (S7)
PFFS4
Paper feed sensor 4
*1
PS1
Paper end sensor 1 (S11)
PFLS1
Paper feed tray limit sensor 1
(S7)
*1
PS2
Paper end sensor 2 (S12)
PFLS2
Paper feed tray limit sensor 2
(S7)
*1
RS1
Registration sensor 1 (S13)
PFLS3
Paper feed tray limit sensor 3
(S7)
*1
RS2
Registration sensor 2 (S14)
*1 Optional paper feed unit
Paper Size Codes
Paper size codes are as follows.
* The unit of Main Scan/Sub Scan Length is 0.1 mm.
Size Code
Paper Size Name
Orientation
Main Scan Length
Sub Scan Length
133(85H)
A4
SEF
2100
2970
134(86H)
A5
SEF
1480
2100
006(06H)
A5
LEF
2100
1480
135(87H)
A6
SEF
1050
1480
142(8EH)
B5
SEF
1820
2570
143(8FH)
B6
SEF
1280
1820
164(A4H)
8 1/2"x14"(LG)
SEF
2159
3556
165(A5H)
8 1/2"x13"(Foolscap)
SEF
2159
3302
166(A6H)
8 1/2"x11"(LT)
SEF
2159
2794
167(A7H)
8 1/4"x14"
SEF
2096
3556
168(A8H)
8 1/4"x13"(Folio)
SEF
2096
3302
169(A9H)
8"x13" (F/GL)
SEF
2032
3302
171(ABH)
8"x10" (UK)
SEF
2032
2540
173(ADH)
7 1/4"x10 1/2"(Executive)
SEF
1842
2667
172(ACH)
5 1/2"x8 1/2"(HLT)
SEF
1397
2159
044(2CH)
5 1/2"x8 1/2"(HLT)
LEF
2159
1397
208(D0H)
No.10 (Com10)
SEF
1048
2413
209(D1H)
No.7 (Monarch)
SEF
984
1905
211(D3H)
C5 Envelope
SEF
1620
2290
212(D4H)
C6 Envelope
SEF
1140
1620
213(D5H)
DL
SEF
1100
2200
195(C3H)
16K
SEF
1950
2670
