8.Smart Operation Panel G2.5
709
Lights when an error occurs.
• Data In indicator (blue)
Flashes when the machine receives data from a printer driver or LAN-
Fax driver.
• Fax indicator (blue)
Flashes while sending or receiving a fax. Lights when there is a
received fax document in the fax memory.
• Media access lamp (blue)
Lights when there is an SD card inserted in the SD card slot.
Maximum power
consumption
4.5 W or less in standby mode (excluding external interfaces and internal
feature expansions)
6 W or less when using wireless LAN (during high-load operation)
Built-in NFC tag
Made by Vanskee Enterprise
RCH-NTI2CP1K-BSA-PCB-CE-1128
Power consumption in
Sleep mode
0.18 W or less
(When in Sleep mode, power is not supplied to USB devices connected to
the USB slots except when the IC card R / W (NFC) is connected.)
Equipped with an angle-adjustable hinge. Clicks at the standard position.
Depending on the model, there is also a hinge-less fixed type.
Specification comparison with the previous model
Control panel size
(Width × Height)
ARM Cortex-A9 Quad Core 1GHz
(SoC: MCIMX6Q5EYM10AD)
ARM Cortex-A9 Dual Core
1GHz
(SoC:
MCIMX6D5EYM10AC)
802.11ac/a/b/g/n (for Taiwan/China/Asia)
802.11b/g/n (2.4GHz only) (for North
America/EU/Korea)
