Ricoh IM 550F

4.Replacement and Adjustment
287
11. Remove the spring [A] and power switch [B].
12. Remove the front cover [A] by releasing the left hinge [B].
Right Cover
1. Remove the upper cover. (Upper Cover)
2. Remove the paper feed tray [A] by pulling it out.
