Ricoh IM 550F

8.Smart Operation Panel G2.5
707
Mechanism
System Components
Hardware Specifications
Components
No.
Name
No.
Name
1
Speaker (OT1)
9
Microphone
2
Main power indicator
10
Extended Feature key (EX3)
3
USB slot for digital cameras
11
Extended Feature key (EX2)
4
USB slot for NFC card readers
12
Extended Feature key (EX1)
5
NFC tag
13
Control panel reboot key
6
[Check Status] indicator
14
SD card slot
7
Data In indicator (facsimile and printer modes)
15
Media access lamp
8
Fax indicator
16
USB slot
Basic Specifications
Category
Specification
LCD panel
• Size
10.1-inch panel
• Resolution
WSVGA (1024x600)
• Bit width
RGB666 (18-bit color)
• Brightness
250cd/m
2
(typ.)
• Backlight
