Ricoh IM 550F

4.Replacement and Adjustment
407
2. Twist the DF rear left cover [B] to release two hooks.
3. Remove the DF rear left cover [A].
DF Rear Right Cover
1. Remove the DF rear left cover. (DF Rear Left Cover)
2. Insert a flathead screwdriver into [A] and [B] to release the hooks on the inside of the DF rear right
cover [C].
3. Push the DF rear right cover [A] towards the machine rear side to release three hooks, and then
