Ricoh IM 550F

2.Installation
180
it in the direction of the blue arrow.
• Be careful not to damage the hooks on the inside of the controller cover when you remove
or install the controller cover.
5. Insert the DataOverwriteSecurity Unit Type M19 SD card in SD Card Slot 1 [A] (upper slot).
6. Reattach the controller cover.
