Ricoh IM 550F

4.Replacement and Adjustment
405
5. Release the flat cable [A] from the harness guide [B] and remove the cores [C].
6. IM 550F/600F: Open the clamp [A] and disconnect the six connectors.
7. IM 600SRF: Open the clamp [A] and disconnect the six connectors. Then release the connectors
from the harness guide [B].
