SATO CL6NX Programming Reference

440
Parameters from here can be specified in any order.
Parameters related to specifying block to start writing (omissible)
wsb:
(former Ws:)
Specify block to start writing Specifies the block to start writing the data. The 0th
block is specified if omitted.
Block is a unit to write to user memory. The following
values in the table are allowed based on the type of
inlets.
A maximum up to a 3-digit decimal can be specified,
but a parameter error occurs if it exceeds the
maximum amount for the specified inlet. Please see
the following table.
Note that the memory address relation is inverted
between when accessing to my-d with iso:0 (custom)
and with iso:1 (ISO) thus the capacity of one block
and total capacity change.
Mapping table of inlet type and number of blocks, and total capacity
Inlet Type Product Capacity
of 1 block.
The number of the
overall blocks.
Total capacity.
ICODE SLI 4bytes 28blocks 112bytes
ICODE SLIX 4bytes 28blocks 112bytes
ICODE(a=2)
ICODE SLIX-S 4bytes 40blocks 160bytes
Tag-it HF-I Plus 4bytes 64blocks 256bytes
Tag-it HF-I Pro 4bytes 8blocks 32bytes
Tag-it(a=3)
Tag-it HF-I
Standard
4bytes 8blocks 32bytes
my-d vp
SRF55V10P
(Custom)
8bytes 125blocks 1000bytesmy-d(a=5)
my-d vp
SRF55V10P
(ISO)
4bytes 248blocks 992bytes
Parameters for Block Lock (omissible)
lbs:
(former Ls:)
Block to start locking Available to specify up to 3 digits in decimals.
A parameter error occurs when it exceeds the
maximum for the specified inlet.
lbn:
(former Ln:)
Number of blocks to lock Available to specify up to 3 digits in decimals.
A parameter error occurs when it exceeds the
maximum for the specified inlet.
Allows to lock specified blocks (making it read-only).
Specify the block to start locking with “lbs:” and specify the number of blocks to lock with “lbn:”.
1 is assigned to “lbn:” if only “lbs:” was specified without specifying “lbn:”.
0 is assigned to “lbs:” if only “lbn” was specified without specifying “lbs”.
The block will not be locked if 0 was specified to “lbn:” or both of the parameters were omitted.
Note that once locked, the block area becomes read-only and cannot be reset.
In applying lock for my-d, specify 1 for “iso:” and access with ISO-15693 standard.
Multiple Block Locks
Supports locking of multiple blocks, up to 16 positions may be locked, and a parameter error will occur if that
number is exceeded. Blocks should be specified with the following pair of parameters: (,lbs:xxx,lbn:yyy). A
