493
Parameters related to specifying block to start writing (omissible)
Cannot be used together with parameters related to
NFC(NDEF).
Parameters related to write block list (omissible)
blt: Write block list It is possible to write to block of uncontinuous data
when specifying a block list format which block
number is delimited by comma.
The scratch pad (user area) of FeliCa Lite/FeliCa
Lite-S comprises 14 blocks, each block can be
specified to 0 ~ 13.
The number of the block list is calculated as 16 bytes
per block, with the condition that the data length
specified by D (or d) parameter fulfills the following
relation:
number of the block list = specified data length ÷ 16
(+1 if there is remainder)
For example, if the data length specified by D (or
d) parameter is 52 bytes, although 52÷16
＝
3, the
number should be 3+1=4 as there is remainder.
If 52 bytes are divided into 4 sets of 16 byte and
write the data to each 0, 2, 8, 13 block, specify as
blt:0,2,8,13.
In the 4th block, the area after the remaining data will
be filled with NULL.
E.g.:
<A>
<RK>4,D52,ABCDEFGHIJKLMNOPQRST
UVWXYZabcdefghijklmnopqrstuvwx
yz,blt:0,1,8,13
<Z>
The scratch pad data after executing the example
above
Block number Data after write
0 ABCD EFGH IJKL
MNOP
1 QRST UVWX YZab
cdef
： ：
8 ghij klmn opqr stuv
： ：
13 wxyz
････
････
････
Note:
• The
････
area is written with NULL.
• No change to the data which block is not specified.
• This data is an example for describing RFID command
output.
Cannot be used together with wsb:.
