Finally, the DS1206N-TS is like the "-TM" version but has no "12V"-to-3.3V power
regulator. Instead, an attached serial device is supposed to provide stabilized 3.3V
power to the board.
Available models and their features
DS1206N-
RS
(RS232)
DS1206N-
TM
(TTL
master)
DS1206N-
TS
(TTL slave)
Setup button
YES
Status LEDs
YES
RS232 transceiver & DB9M
connector
YES
NO
TTL interface connector
NO
YES
Power switch
YES
NO
Power jack and "12V"-to-3.3V
regulator
YES
NO
Hardware features
· Superior upgrade to the EM1202EV board.
· Based on a high-performance purpose-built 88-MHz T1000 ASIC.
· Powered by Tibbo OS (TiOS).
· 10/100BaseT auto-MDIX Ethernet port (automatic detection of "straight" and
"cross" cables).
· Up to 3.5 serial channels:
- DS1206N-RS: RS232 port (DB9M connector);
- DS1206N-TM and "-TS": TTL serial port (pin header);
- Baudrates of up to 921,600bps;
- None/even/odd/mark/space parity modes;
- 7/8 bits/character modes;
- Full-duplex mode with optional flow control;
- DS1206N-TM and "-TS": half-duplex mode with direction control;
- Flexible mapping with 15 different options, such as:
- A single channel: RX, TX, CTS, RTS, DSR, and DTR lines;
- 3.5 channels: RX, TX, RX2, TX2, RX3, TX3, and RX4 lines.
- DS1206N-RS: optional "12V" power output on DB9M connector (software-
controllable);
- DS1206N-TM: optional "12V" power input from the serial port (instead of supplying
power through the power jack).
· 512KB or 1024KB flash memory for firmware, application, and data storage.
· 2KB EEPROM for data storage.
· Four LEDs:
- Green and red status LEDs on top of the device;
- Link and speed Ethernet status LEDs on the RJ45 jack.
