492Sensors (Probes)
© Tibbo Technology Inc.
Additional registers of BP#02 (ambient temperature and
relative humidity sensor)
Ad
dr.
Name
R
/
W
Type
Description
0x
40
0
TEMP_
PROC
R
Sign
ed
16-
bit
Processed fixed-point temperature data expressed
in steps of 0.1 degrees C.
Measurement resolution is 0.5 degrees C.
0x
40
1
TEMP_
RAW
R
Unsig
ned
16-
bit
Raw temperature data from the measurement IC
(HIH6130).
See vendor datasheet for details.
0x
40
4
HUM_P
ROC
R
Unsig
ned
16-
bit
Processed fixed-point relative humidity data
expressed in steps of 0.1%.
Measurement resolution is 0.1%.
0x
40
5
HUM_R
AW
R
Unsig
ned
16-
bit
Raw humidity data from the measurement IC
(HIH6130).
See vendor datasheet for details.
R = read (only)
Additional registers of BP#03 (ambient light sensor)
Ad
dr.
Name
R/
W
Typ
e
Description
0x
50
0
LUM_PR
OC
R
Unsi
gned
16-
bit
Processed fixed-point luminance data expressed in
steps of 1 Lux.
Measurement resolution is 1 Lux.
0x
50
1
LUM_R
AW
R
Unsi
gned
16-
bit
Raw luminance data from the measurement IC
(BH1721FVC).
See vendor datasheet for details.
R = read (only)
Additional registers of BP#04 (3-axis accelerometer)
