3-12 Phaser 6180 Color Laser Printer Service Manual
Error Messages and Codes
14 Check the Drive Assembly signal.
1. Disconnect P/J25 on the MCU
Board.
2. Is there +24 V across ground <=>
J25-1/J25-2?
Replace the
Drive Assembly
(page 8-76).
Replace the
MCU Board
(page 8-87).
15 Perform the Tray 2 Feed Clutch test
(page 4-54): Service Mode > Engine
Diag > Motor Test > Tray 2 Feed
Clutch.
Does the Clutch operate properly?
Replace the
MCU Board
(page 8-87).
Go to step 16.
16 Check the wiring harness connectors
P/J23 and P/J235 between the MCU
Board and the Feed Clutch. Are the
connectors securely connected?
Replace the
Right Side
Harness.
Reconnect the
connectors.
17 Check the Right Side Harness for
continuity.
1. Disconnect P/J25 and P/J251.
2. Check continuity between P/J25 <=>
P/J251.
Go to step 18. Replace the
Right Side
Harness.
18 Check the Feed Clutch signal.
1. Disconnect P/J23 on the MCU
Board.
2. Is there +24 V across ground <=>
J23-15?
Replace the Tray
2 Feed Clutch
(page 8-42).
Replace the
MCU Board
(page 8-87).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
To Next Page
