3-14 Phaser 6180 Color Laser Printer Service Manual
Error Messages and Codes
5 Perform the Registration Sensor test
(page 4-29): Service Mode > Engine
Diag > Sensor Test > Regi Sensor.
Does the number on the Control Panel
increase by 1 when the Actuator of the
Registration Sensor is activated?
Go to step 10. Go to step 6.
6 Check the wiring harness connectors
P/J23, P/J232, and P/J2322 between
the MCU Board and the Registration
Sensor. Are the connectors securely
connected?
Go to step 7. Reconnect the
connectors.
7 Check the Registration Sensor
Harness for continuity.
1. Disconnect P/J232 and P/J2322.
2. Check continuity between P/J232
<=> P/J2322.
Go to step 8. Replace the
Registration
Sensor
Harness.
8 Check the Right Side Harness for
continuity.
1. Disconnect P/J23 and P/J232.
2. Check continuity between P/J23 <=>
P/J232.
Go to step 9. Replace the
Right Side
Harness.
9 Check the Registration Sensor signal.
Disconnect P/J23 on the MCU Board.
Is there +3.3 V across ground <=>
J23-8?
Go to step 10. Replace the
MCU Board
(page 8-87).
10 Perform the Tray 3 Feed Motor test
(page 4-45): Service Mode > Engine
Diag > Motor Test > Tray 3 Feed
Motor.
Does the Motor operate properly?
Go to step 18. Go to step 11.
11 Check the wiring harness connectors
P/J422 and P/J4222 between the Tray
3 Feeder Board and the Tray 3 Feeder
Drive. Are the connectors securely
connected?
Go to step 9. Reconnect the
connectors.
12 Check the C2 Motor Harness for
continuity.
1. Disconnect P/J422 and P/J4222.
2. Check continuity between P/J422
<=> P/J4222.
Go to step 13. Replace the C2
Motor Harness.
13 Check the Tray 3 Feeder Drive signal.
1. Disconnect P/J4222 on the Optional
Feeder Board.
2. Is there +24 V across ground <=>
J422-6?
Replace the Tray
3 Feeder Drive
(page 8-106).
Go to step 14.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
To Next Page
