Phaser 6180 Color Laser Printer Service Manual 3-67
Error Messages and Codes
13 Check the wiring harness connectors
P/J419, P/J273, and P/J27. Are the
connectors securely connected?
Go to step 14. Reconnect the
connectors. Go
to step 14.
14 Check the Optional Feeder Harness for
continuity.
1. Disconnect P/J419 and P/J273.
2. Check continuity between P/J419
<=> P/J273.
Go to step 15. Replace the
Optional Feeder
Harness.
15 Check the Right Side Harness for
continuity.
1. Disconnect P/J273 and P/J27.
2. Check continuity between P/J273
<=> P/J27.
Go to step 16. Replace the
Right Side
Harness.
16 Check the Optional Feeder Board
signal.
1. Disconnect P/J27 on the MCU
Board.
2. Is there +3.3 V across ground <=>
J27-7?
Replace the Tray
3 Feeder
(page 8-102).
Replace the
MCU Board
(page 8-87).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
