4-74 Phaser 6180 Color Laser Printer Service Manual
General Troubleshooting
5 1. Check the Main Drive for correct
installation.
2. Reseat the Main Drive.
3. Perform the Main Motor test (page 4-40):
Service Mode > Engine Diag > Motor
Test > Main Motor.
4. Does the noise come from the printer?
Replace the
following
parts, one
after another.
■ Fuser
(page 8-10)
■ Black Print
Cartridge
(page 8-9)
■ Transfer
Unit
(page 8-7)
■ Main Drive
(page 8-73)
Complete.
6 Perform the Sub Motor test (page 4-41):
Service Mode > Engine Diag > Motor Test
> Sub Motor.
Does the noise come from the printer?
Go to step 7. Go to step 9.
7 1. Check the Print Cartridges for correct
installation.
2. Reseat the Print Cartridges.
3. Perform the Sub Motor test (page 4-41):
Service Mode > Engine Diag > Motor
Test > Sub Motor.
4. Does the noise come from the printer?
Go to step 8. Complete.
8 1. Check the Main Drive for correct
installation.
2. Reseat the Main Drive.
3. Perform the Sub Motor test (page 4-41):
Service Mode > Engine Diag > Motor
Test > Sub Motor.
4. Does the noise come from the printer?
Replace the
following
parts, one
after another.
■ Print
Cartridges (C/
M/Y/K)
(page 8-9)
■ Main Drive
(page 8-73)
Complete.
9 Perform the Deve Motor test (page 4-43):
Service Mode > Engine Diag > Motor Test
> Deve Motor. Does the noise come from
the printer?
Go to step 10. Go to step 12.
10 1. Check the Print Cartridges for correct
installation.
2. Perform the Deve Motor test (page 4-43):
Service Mode > Engine Diag > Motor
Test > Deve Motor.
3. Does the noise come from the printer?
Go to step 11. Complete.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
