Phaser 6180 Color Laser Printer Service Manual 4-75
General Troubleshooting
11 1. Check the Main Drive for correct
installation.
2. Perform the Deve Motor test (page 4-43):
Service Mode > Engine Diag > Motor
Test > Deve Motor.
3. Does the noise come from the printer?
Replace the
following
parts, one
after another.
■ Print
Cartridges (C/
M/Y/K)
(page 8-9)
■ Main Drive
(page 8-73)
Complete.
12 1. Check the Drive Assembly for correct
installation.
2. Perform the Tray 2 Motor test
(page 4-42): Service Mode > Engine
Diag > Motor Test > Tray 2 Motor.
3. Does the noise come from the printer?
Go to step 14. Complete, if
the Optional
550-Sheet
Feeder is
installed.
13 Perform the Option Feeder Motor test
(page 4-45): Service Mode > Engine Diag
> Motor Test > Tray 3 Feed Motor.
Does the noise come from the printer?
Replace the
Tray 3 Feeder
(page 8-102).
Complete.
14 1. Check the Drive Assembly for correct
installation.
2. Perform the Tray 2 Motor test
(page 4-42): Service Mode > Engine
Diag > Motor Test > Tray 2 Motor.
3. Does the noise come from the printer?
Replace the
Drive
Assembly
(page 8-76).
Complete.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
