Phaser 6280 Color Laser Printer Service Manual 4-15
General Troubleshooting
Tray 3 Feed
Motor (Full2)
Tray 3 Feed Motor
(FULL2)
Tests the Tray 3 Feed Motor.
Tray 3 Feed
Motor (Half)
Tray 3 Feed Motor
(HALF)
Fan (High) Fan (HIGH) Tests the printer Fan.
Fan (Low) Fan (LOW)
Yellow Toner
Motor
Yellow Toner Motor Tests the yellow Toner Motor.
Magenta Toner
Motor
Magenta Toner Motor Tests the magenta Toner Motor.
Cyan Toner
Motor
Cyan Toner Motor Tests the cyan Toner Motor.
Black Toner
Motor
Black Toner Motor Tests the black Toner Motor.
Regi Clutch Regi Clutch Tests the Registration Clutch.
Tray1 (MPT)
Turn Clutch
Tray1(MPT) Turn Clutch Tests the Tray 1 Turn Clutch.
Tray 1 (MPT)
Feed Solenoid
Tray1(MPT) Feed
Solenoid
Tests the Tray 1 Feed Solenoid.
Tray 2 Feed
Clutch
Tray 2 Feed Clutch Tests the Tray 2 Feed Clutch.
Tray 3 Feed
Clutch
Tray 3 Feed Clutch Tests the Tray 3 Feed Clutch.
Tray 3 Turn
Clutch
Tray 3 Turn Clutch Tests the Tray 3 Turn Clutch.
Duplex Clutch Duplex Clutch Tests the Duplex Clutch.
ADC (TCD)
Sensor
Solenoid
ADC (TCD) Sensor
Solenoid
Tests the ADC Sensor Solenoid.
ADC (TCD)
Sensor LED
ADC (TCD) Sensor LED Tests the ADC Sensor LED.
OHP Sensor
LED
OHP Sensor LED Tests the OHP Sensor LED.
Drum Erase
Lamp K
Drum Erase Lamp K Tests the black Erase Lamp.
Drum Erase
Lamp YMC
Drum Erase Lamp YMC Tests the yellow, magenta, and cyan
Erase Lamps.
Exit Clutch Exit Clutch Tests the Exit Clutch.
Duplex Fan Duplex Fan Tests the Duplex Fan.
Buzzer On Buzzer On Tests buzzer On.
Service Diagnostic Test Table (continued)
Test Control Panel Display Test Description
