Xerox Phaser 6280 Service Manual

4-16 Phaser 6280 Color Laser Printer Service Manual
General Troubleshooting
K Mode Clutch
On
K Mode Clutch On Tests the K Mode Clutch.
NVM Settings <Press the Up or Down
button to move from one
item to another>
<Press the Cancel button
to move one level up the
menu>
<Press the Set button to
move to the execution
level>
Edits, saves, loads, and prints NVRAM
information.
Edit NVM Edit NVM
■ Ad0000=00000000*
■ Please wait
<Press the Left or Right
button to move the
cursor>
<Press the Up or Down
button to change the
value at the cursor>
<Press the Set button to
save the value in Engine
NVM>
<Press the Cancel button
to move one level up the
menu>
Displays the current NVRAM value.
Use this function to edit NVRAM
information.
Save NVM to
ESS
Save NVM to ESS
■ SaveNVM to ESS OK?
■ Processing
■ Saved
■ Please wait
<Press the Set button to
save the value in the
Controller NVM>
<Press the Cancel button
to move one level up the
menu>
Saves the NVRAM information of the
Engine in the Controller. NVRAM
addresses to be saved are as follows:
1000-10FF, Total: 256Byte
Note: Information saved in the
Controller NVM can be initialized using
Clear All NVM.
Load NVM Load NVM
■ LoadNVM from ESS
OK?
■ Processing
■ Loaded
■ Please wait
<Press the Set button to
load the value saved in
the Controller NVM to the
Engine>
<Press the Cancel button
to move one level up the
menu>
Loads NVRAM information of the
Engine saved in the Controller into the
Engine.
1000-10FF / 1100-11FF / 1200-12FF
Note: Information saved in the
Controller NVM can be initialized using
Clear All NVM.
Service Diagnostic Test Table (continued)
Test Control Panel Display Test Description
