Xerox Phaser 6280 Service Manual

Phaser 6280 Color Laser Printer Service Manual 4-17
General Troubleshooting
Initialize Slave Initialize Slave
■ Initialize Slave OK?
■ Processing
■ Initialized
■ Please wait
<Press the Set button to
run Slave Initialization>
<Press the Cancel button
to move one level up the
menu>
Initializes Slave.
Print NVM Info Print NVM Info
■ Processing
■ Please wait
<Press the Set button to
run the test>
<Press the Cancel button
to move one level up the
menu>
Prints NVRAM information saved in the
Controller.
Print Info Provides printer configurations and settings information.
Menu Buttons
<Press the Up or Down
button to move from one
item to another>
<Press the Cancel button
to move one level up the
menu>
<Press the Set button to
move to the execution
level>
Info Page Info Page
■ Ready
■ Processing
Prints the software version of the
printer controller. Use this function to
verify the printer configuration. The
Configuration Page contains:
■ Engine installation unit information
■ Standard Tray
■ Optional Tray (displaying version)
■ Optional Duplex Unit (displaying
version)
■ Engine ROM Revision No.
■ MCU NVM Revision No.
Service Diagnostic Test Table (continued)
Test Control Panel Display Test Description

Xerox Phaser 6280 Specifications

General

Print Resolution	Up to 600 x 600 x 4 dpi
Processor	400 MHz
Operating System Compatibility	Windows, Mac OS, Linux
Print Technology	Laser
Monthly Duty Cycle	70, 000 pages
Memory	256 MB (standard)
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Legal, Letter
Maximum Paper Size	8.5 x 14 inches
