Phaser 6280 Color Laser Printer Service Manual 4-79
General Troubleshooting
14 1.Perform the Sub Motor test (page 4-42):
Service Mode > Engine Diag > Motor
Test > Sub Motor.
2.Does the noise come from the motor?
Replace the
Main Drive
Assembly
(
page 8-70).
Go to step 15.
15 1.Perform the Tray 2 Motor test
(page 4-43): Service Mode > Engine
Diag > Motor Test > Tray 2 Motor.
2.Does the noise come from the motor?
Replace the
PH Drive
Assembly
(
page 8-73).
Complete.
If the
Optional Tray
is installed,
go to step 16.
16 1.Perform the Tray 3 Feed Motor test
(page 4-45): Service Mode > Engine
Diag > Motor Test > Tray 3 Motor.
2.Does the noise come from the motor?
Replace the
Optional 550-
Sheet Feeder
(
page 8-100).
Complete.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6280 Specifications

General

Print Resolution	Up to 600 x 600 x 4 dpi
Processor	400 MHz
Operating System Compatibility	Windows, Mac OS, Linux
Print Technology	Laser
Monthly Duty Cycle	70, 000 pages
Memory	256 MB (standard)
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Legal, Letter
Maximum Paper Size	8.5 x 14 inches
