YASKAWA V1000 Series

No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
OL
V
PM
H2-06 Watt Hour Output Unit Selection
Sets the display units for one of the multi-function output
terminals that is assigned to output the watt hours (H2-฀฀ =
39) is the value every 200 ms. An output pulse of 200 ms is
provided for every kWh that occurs. Intended to drive a
counter, meter or PLC for logging kWh.
0: 0.1 kWh units
1: 1 kWh units
2: 10 kWh units
3: 100 kWh units
4: 1000 kWh units
0 to 4 0 A A A 437 —
<40> The availability of certain functions depends on the control method used.
H2 Multi-Function Digital Output Settings
H2-oo
Setting
Function Description
Control
Mode
Pg.
V/f
OL
V
PM
0 During Run Closed: A Run command is active or voltage is output. O O O —
1 Zero Speed Closed: Output frequency is 0. O O O —
2 Fref/Fout Agree 1 Closed: Output frequency equals the speed reference (plus or minus the hysteresis set to L4-02). O O O —
3 Fref/Fset Agree 1 Closed: Output frequency and speed reference equal the value in L4-01 (plus or minus the hysteresis of L4-02). O O O —
4 Frequency (FOUT) Detection 1 Closed: Output frequency is less than or equal to the value in L4-01 with hysteresis determined by L4-02. O O O —
5 Frequency (FOUT) Detection 2 Closed: Output frequency is greater than or equal to the value in L4-01, with hysteresis determined by L4-02. O O O —
6 Drive Ready Closed: Drive Ready. The drive is powered up, not in a fault state, and in the Drive mode. O O O —
7 DC Bus Undervoltage Closed: DC bus voltage is below the UV trip level set in L2-05. O O O —
8 During Baseblock Closed: This is no output voltage O O O —
9 Option Reference Closed: Digital operator supplies the frequency reference. O O O —
A Local/Remote
Open: Reference 1 or 2 are active
Closed: Digital operator supplies the run command.
O O O —
B Torque Detection 1 (N.O.)
Closed: Output current/torque exceeds the torque value set in parameter L6-02 for longer than the time set in
parameter L6-03.
O O O —
C Loss of Reference Closed: Loss of the analog frequency reference detected. Enabled when L4-05 = 1. O O O —
D Braking Resistor Fault
Closed: Braking resistor or transistor is overheated or faulted out. This selection requires that braking resistor
protection parameter be set for ERF (L8-01 = “1”).
O O O —
E Fault Closed: Fault occurred (other than CPF00 and CPF01). O O O —
F Not used Set this value when the terminal is not used, or when using the terminal in the pass-through mode. O O O —
10 Alarm Closed: An alarm is triggered. O O O —
11 Reset Command Active Closed: Reset command to the drive is active. O O O —
12 Timer Output
Timer output, controlled by b4-01 and b4-02. Used in conjunction with the digital input (H1-oo = 18 “timer
function”).
O O O —
13 Fref/Fout Agree 2 Closed: When drive output frequency equals the frequency reference +/- L4-04. O O O —
14 Fref/Fset Agree 2 Closed: When the drive output frequency is equal to the value in L4-03 (plus or minus L4-04). O O O —
15 Frequency Detection 3
Closed: When the drive output frequency is less than or equal to the value in L4-03 with the hysteresis determined
by L4-04.
O O O —
16 Frequency Detection 4
Closed: When the output frequency is greater than or equal to the value in L4-03 with the hysteresis determined
by L4-04.
O O O —
17 Torque Detection 1 (N.C.)
Open: When the output current/torque exceeds the value set in parameter L6-02 for more time than is set in
parameter L6-03.
O O O —
18 Torque Detection 2 (N.O.)
Closed: When the output current/torque exceeds the value set in parameter L6-05 for more time than is set in
parameter L6-06.
O O O —
19 Torque Detection 2 (N.C.)
Open: Output current/torque exceeds the value set in parameter L6-05 for more time than is set in parameter
L6-06.
O O O —
1A Reverse Direction Closed: Drive is running in the reverse direction. O O O —
1B Baseblock 2 Open: Drive is in base block condition. Output is disabled. O O O —
1C Motor 2 Selection
Closed: Motor 2 is selected by a digital input (H1-oo = 16)
O O − —
1E Restart Enabled Closed: An automatic restart is performed O O O —
1F Overload Alarm OL1 Closed: OL1 is at 90% of its trip point or greater. O O O —
20 OH Pre alarm Closed: Heatsink temperature exceeds the parameter L8-02 value. O O O —
22 Mechanical Weakening (N.O.) Closed: Mechanical Weakening detected. O O O —
30 During Torque Limit Closed: When the torque limit has been reached. − O − —
37 During Frequency Output
Closed: Frequency is output
Open: Operation stopped, Baseblock, DC Injection Braking, or Initial Excitation is being performed.
O O O —
38 Drive Enable
Closed: Multi-function input closes (H1-oo = 6A)
O O O —
39 Watt Hour Pulse Output Output units are determined by H2-06, outputs 200 ms pulse for each incremented kWh count. O O O —
3C Drive Mode
Closed: Local
Open: Remote
(this signal combines setting values 9 and A)
O O O —
3D Speed Search Closed: Speed search is being executed. O O O —
3E PID Feedback Loss
Closed: PID Feedback Loss.
PID feedback value is below the level set to b5-13 for longer than the time set in b5-14.
O O O —
3F PID Feedback Fault
Closed: PID Feedback Fault.
PID feedback value exceeds the level set to b5-36 for longer than the time set to b5-37.
O O O —
4A KEB Operation Closed: KEB is being performed. O O O —
4B Short-Circuit Brake Closed: Short-Circuit Braking is active. − − O —
4C During Fast-stop Closed: Fast-stop command is entered O O O —
4D OH Pre-alarm Time Limit Closed: OH Pre-alarm time limit is passed. O O O —
B.2 Parameter Table
