YASKAWA V1000 Series

H2 Multi-Function Digital Output Settings
H2-oo
Setting
Function Description
Control
Mode
Pg.
V/f
OL
V
PM
100 to 14D
H2 Parameter Functions Reversed Output
Switching of 0 to 92
Reverse the output switching of the multi-function output functions. Set the last two digits of 1oo to reverse the
output signal of that specific function.
Examples:
Setting “108” reverses the output of “During baseblock,” which is setting value 08.
Setting “14A” reverses the output of “During KEB operation”, which is setting “4A”.
O O O —
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
OL
V
PM
H3: Analog Inputs
Use H3 parameters to set the multi-function analog input terminals.
H3-01 Terminal A1 Signal Level Selection
Sets the input level for terminal A1.
0: 0 to +10 V (lower limit)
1: 0 to +10 V (no lower limit)
0, 1 0 A A A 410 —
H3-02 Terminal A1 Function Selection
Sets the function of terminal A1.
When terminal A1 is not used or is used as a through terminal, this parameter
must be set to “F”.
0 to 31 <40> 0 A A A 434 —
H3-03 <22>
Terminal A1 Gain Setting
Sets the level of the input value selected in H3-02 when 10V is input at terminal
A1.
-999.9 to 999.9 100.0% A A A 411 —
H3-04 <22>
Terminal A1 Bias Setting
Sets the level of the input value selected in H3-02 when 0V is input at terminal
A1.
-999.9 to 999.9 0.0% A A A 412 —
H3-09 Terminal A2 Signal Level Selection
Sets the input signal level for terminal A2.
0: 0 to +10 V (with lower limit)
1: 0 to +10 V (no lower limit)
2: 4 to 20 mA
3: 0 to 20 mA
0 to 3 2 A A A 417 —
Switch between current or voltage inputs by using DIP switch
S1-2 switch on the terminal board. Refer to I/O
Connections on page 48.
H3-10 Terminal A2 Function Selection
Sets the function of terminal A2.
When terminal A2 is not used or is used as a through terminal, this parameter
must be set to “F”.
0 to 31 <40> 0 A A A 418 —
H3-11 <22>
Terminal A2 Gain Setting
Sets the level of the input value selected in H3-10 when 10 V (20 mA) is input
at terminal A2.
-999.9 to
1000.0
100.0% A A A 419 —
H3-12 <22>
Terminal A2 Input Bias
Sets the level of the input value selected in H3-10 when 0 V (0 or 4 mA) is input
at terminal A2.
-999.9 to 999.- 0.0% A A A 41A —
H3-13 Analog Input Filter Time Constant
Sets the primary delay filter time constant for terminals A1 and A2. Used for
noise filtering.
0.00 to 2.00 0.03 s A A A 41B —
<22> Parameter can be changed during run.
<40> The availability of certain parameters depends on the control method used.
H3 Multi-Function Analog Input Settings
H3-oo
Setting
Function Maximum Input Level Possible
Control Mode
Pg.
V/f OLV PM
0 Frequency Bias
Max output frequency (E1-04).
Same value can be set using H3-02 and H3-10.
O O O —
1 Frequency Gain Frequency reference (voltage) O O O —
2
Auxiliary Frequency Reference (used as a multi step speed
2)
Max output frequency (E1-04) O O O —
4 Output Voltage Bias Motor rated voltage (E1-05). O – − —
7 Overtorque/Undertorque Detection Level
Open Loop Vector: Motor rated torque
V/f control: Drive rated current
O O O —
B PID Feedback 10V = 100% O O O —
C PID Set Point 10V = 100% O O O —
E Motor Temperature (PTC input)
10 V = 100.00%
Determined by L1-03 and L1-04.
O O O —
F Not used / Pass-through mode – O O O —
10 FWD Torque Limit Motor rated torque − O − —
11 REV Torque Limit Motor rated torque − O − —
12 Regenerative Torque Limit Motor rated torque − O − —
15 FWD/REV Torque Limit Motor rated torque − O − —
16 Differential PID Feedback 10 V = 100% O O O —
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
OL
V
PM
H4: Multi-Function Analog Outputs
Use H4 parameters to configure the multi-function analog output terminals.
H4-01
Multi-Function Analog Output
Terminal AM)
Selects the data to be output through multi-function analog output terminal AM.
Set the desired monitor parameter to the digits available in Uo-oo. For
example, enter “103” for U1-03.
When using this terminal in trough mode or when not using it at all, set “000”
or “031”.
000 to 999
<40>
102 A A A 41D —
H4-02 <22> Multi-Function Analog Output
Terminal AM Gain
Sets terminal AM output level when selected monitor is at 100%.
Maximum output voltage is 10 V.
-999.9 to
999.9
100.0% S S S 41E —
H4-03
<22>
Multi-Function Analog Output
Terminal AM Gain
Sets terminal AM output level when selected monitor is at 0%.
-999.9 to
999.9
0.0% A A A 41F —
B.2 Parameter Table
YASKAWA ELECTRIC SIEP C710606 18A YASKAWA AC Drive – V1000 Technical Manual (Preliminary)
309
B
Parameter List
