Configuring LAG Introduction
4-27
Software Reference for SwitchBlade x3100 Series Switches (Layer Two Switching)
The following procedure shows the commands used to create the LAG shown in Figure 4-2.
TABLE 4-3 Configuration Procedure for Creating a Cross-Card LAG
Step Command Description/Notes
Ensure that physical interfaces that you wish to combine into a LAG have matching provisioning attributes (e.g., VLAN
configuration, speed, duplex, auto-negotiation, direction, etc.)
Show the first two interfaces (0.8 and 0.9) designated for the LAG
1
show interface 0.8 full
--- GE Interfaces ---
Interface.......................... 0.8
Type............................... GE
State.............................. UP-UP-Online
Description........................ <none>
Remote ID.......................... <none>
External Profile................... <none>
Card Type.......................... GE24SFP
Provisioning
Provisioning Profile............ AutoProv (*)
Direction....................... Network
Auto Negotiation................ On
Speed........................... Auto
Duplex.......................... Full
Flow Control.................... Auto
Remote Monitoring............... On
Actual
Direction....................... Network
Physical Address................ EC:CD:6D:03:6E:F7
Speed........................... 1 Gbps
Duplex.......................... Full
Flow Control.................... Off
VLAN Information
Acceptable Frame Types.......... All
Ingress Filtering............... On
TPID............................ 0x8100
TAGALL.......................... Off
Dynamic MAC Learning Limit...... 0
Untagged VLAN................... 1500
Packet Statistics
Input Output
------------- -------------
Octets.......................... 0 0
Unicast Packets................. 0 0
Discarded Packets............... 0 0
Errored Packets................. 0 0
