Introduction Configuring LAG
Software Reference for SwitchBlade x3100 Series Switches (Layer Two Switching)
4-28
2
show interface 0.9 full
--- GE Interfaces ---
Interface.......................... 0.9
Type............................... GE
State.............................. UP-DN-Failed
Description........................ <none>
Remote ID.......................... <none>
External Profile................... <none>
Card Type.......................... GE24SFP
Interface Faults
Loss of Link.................... Major
Provisioning
Provisioning Profile............ AutoProv (*)
Direction....................... Network
Auto Negotiation................ On
Speed........................... Auto
Duplex.......................... Full
Flow Control.................... Auto
Remote Monitoring............... On
Actual
Direction....................... Network
Physical Address................ EC:CD:6D:03:6E:F8
Speed........................... 1 Gbps
Duplex.......................... Full
Flow Control.................... Off
VLAN Information
Acceptable Frame Types.......... All
Ingress Filtering............... On
TPID............................ 0x8100
TAGALL.......................... Off
Dynamic MAC Learning Limit...... 0
Untagged VLAN................... 1500
Packet Statistics
Input Output
------------- -------------
Octets.......................... 0 0
Unicast Packets................. 0 0
Discarded Packets............... 0 0
Errored Packets................. 0 0
Create the LAG - with the 2 matching interfaces
3
create lag sfp interface 0.8,0.9 mode on Creates a LAG with an ID of “sfp,” enables link
aggregation for the LAG, and includes interfaces
0.8 and 0.9 in the LAG.
Show the 3rd interface (to be added to the LAG)
TABLE 4-3 Configuration Procedure for Creating a Cross-Card LAG
Step Command Description/Notes
