1. INTRODUCTION
DHW – Double Hardware Width: Nexto Series modules were designed to save space in user cabi-
nets or machines. For this reason, Nexto Series delivers two different module widths: Double Width
(two backplane rack slots are required) and Single Width (only one backplane rack slot is required).
This concept allows the use of compact I/O modules with a high-density of I/O points along with
complex modules, like CPUs, fieldbus masters and power supply modules.
High-speed CPU: All Nexto Series CPUs were designed to provide an outstanding performance to
the user, allowing the coverage of a large range of applications requirements.
iF Product Design Award 2012: Nexto Series was the winner of iF Product Design Award 2012
in industry + skilled trades group. This award is recognized internationally as a seal of quality and
excellence, considered the Oscars of the design in Europe..
1.3. Documents Related to this Manual
In order to obtain additional information regarding the Nexto Series, other documents (manuals and technical features)
besides this one, may be accessed. These documents are available in its last version on the site http://www.altus.com.br/site_
en/.
Each product has a document designed by Technical Features (CE), where the product features are described. Furthermore,
the product may have Utilization Manuals (the manuals codes are listed in the CE).
For instance, the NX2020 module has the information for utilization features and purchasing on its CE. On another hand,
the NX5001 has, besides the CE, a User Manual (MU).
It is advised the following documents as additional information source:
Code Description Language
CE114000 Nexto Series – Technical Characteristics English
CT114000 Série Nexto – Características Técnicas Portuguese
CS114000 Serie Nexto – Características Técnicas Spanish
CE114102 NX3030 Technical Characteristics English
CT114102 Características Técnicas NX3030 Portuguese
CS114102 Especificaciones y Configuraciones NX3030 Spanish
CE114200 NX8000 Power Supply Module Technical Characteristics English
CT114200 Características Técnicas Fonte de Alimentação NX8000 Portuguese
CS114200 Características Técnicas del Fuente de Alimentación NX8000 Spanish
CE114700 Nexto Series Backplane Racks Technical Characteristic English
CT114700 Características Técnicas dos Bastidores da Série Nexto Portuguese
CS114700 Características Técnicas de los Bastidores de la Serie Nexto Spanish
CE114810
Nexto Series Accessories for Backplane Rack Technical
Characteristics
English
CT114810 Características Técnicas Acessórios para Bastidor Série Nexto Portuguese
CS114810 Características Técnicas del Cierres Laterales para el Bastidor Spanish
CE114900 NX4010 Redundancy Link Module Technical Characteristics English
CT114900 Características Técnicas do Módulo de Redundância NX4010 Portuguese
CS114900 Características Técnicas del Módulo de Redundancia NX4010 Spanish
CE114902 Nexto Series PROFIBUS-DP Master Technical Characteristics English
CT114902 Características Técnicas do Mestre PROFIBUS-DP da Série Nexto Portuguese
CS114902 Características Técnicas del Módulo Profibus-DP Maestro Spanish
CE114903 Nexto Series Ethernet Module Technical Characteristics English
CT114903 Características Técnicas Módulo Ethernet Série Nexto Portuguese
CS114903 Características Técnicas del Modulo Ethernet Série Nexto Spanish
CE114908 NX5110 and NX5210 PROFIBUS-DP Heads Technical Characteristics English
CT114908
Características Técnicas Interfaces Cabeça PROFIBUSDP NX5110 e
NX5210
Portuguese
CS114908
Especificaciones y Configuraciones PROFIBUS-DP Interfaz Cabezas
NX5110 y NX5210
Spanish
