8. ANNEX. DNP3 INTEROPERABILITY
8. Annex. DNP3 Interoperability
8.1. DNP3 Device Profile
DNP3
DEVICE PROFILE DOCUMENT
Device Identification
Vendor Name Altus S/A
Device Name NX3030
Device Function Slave
DNP Levels Supported for
Requests: None
Responses: None
Connections Supported IP Networking
Methods to set Configurable Parameters Software: MasterTool IEC XE
IP Networking
Type of End Point: TCP Listening (Outstation Only)
Accepts TCP Connections from Allows all
IP Address(es) from which TCP Connec-
tions are accepted:
*.*.*.*
TCP Listen Port Number Configurable, range 1 to 65535
TCP Keep-alive timer Configurable, range 0 to 4294967295
Multiple master connections
Supports up to two masters
Based on TCP port number
Time synchronization support SNTP
Link Layer
Data Link Address Configurable, range 0 to 65519
Self Address Support using address
0xFFFC
No
Requires Data Link Layer Confirmation Never
Maximum number of octets Transmitted in
a Data Link Frame
Fixed at 292
Maximum number of octets that can be Re-
ceived in a Data Link Frame
Fixed at 292
Application Layer
Maximum number of octets Transmitted in
an Application Layer Fragment
Fixed at 2048
Maximum number of octets that can be re-
ceived in an Application Layer Fragment
Fixed at 2048
Time-out waiting for Application Confirm
of solicited response message
Fixed at 10000 ms
Device Trouble Bit IIN1.6 This bit will be set if PLC is not in RUN mode
Event Buffer Overflow Behavior Discard the oldest event
Sends Multi-Fragment Responses Yes
Outstation Unsolicited Response Support
Supports Unsolicited Reporting No
Table 248: DNP3 Device Profile
377
