5. CONFIGURATION
Enumerator Value Description
SNTP_NOT_ENABLE (11)
Error generated when the SNTP
service is not enabled and it is done
an attempt for modifying the time
zone.
Table 167: RTC_STATUS
5.8.2.4. TIMEZONESETTINGS
This structure is used to store the time zone value in the reading/setting requests of the RTC’s function blocks and it is
described in table below:
Structure Type Variable Description
TIMEZONESETTINGS INT iHour Set time zone hour.
INT iMinutes Set time zone minute.
Table 168: TIMEZONESETTINGS
Note:
Function Blocks of Writing and Reading of Date and Hour: different libraries of NextoStandard, which have function
blocks or functions that may perform access of reading and writing of date and hour in the system, are not indicated. The
NextoStandard library has the appropriate interfaces for writing and reading the system’s date and hour accordingly and for
informing the correct diagnostics.
5.9. User Files Memory
Nexto Series CPUs have a memory area destined to the general data storage, in other words, the user can store several
project files of any format in the CPU memory. This memory area varies according to the CPU model used (check Memory
section).
In order to use this area, the user must access a project in the MasterTool IEC XE software and click on the Devices Tree,
placed at the program left. Double click on the Device item and, after selecting the CPU in the Communication Settings tab
which will be open, select the Files tab and click on Refresh, both in the computer files column (left) and in the CPU files
column (right) as shown on figure below.
Figure 133: User Files Access
After updating the CPU column of files, the root directory of files stored in the CPU will be shown. Then it will be possible
to select the folder where the files will be transferred to. The “InternalMemory” folder is a default folder to be used to store
224
