6. REDUNDANCY WITH NX3030 CPU
Below, is exemplified how the user can manage failures and execute a switchover due to an error in the Ethernet interfaces
from the Active PLC (this code should be used in the ActivePrg POU):
//Verify if NIC Teaming is enabled.
IF ((DG_NX3030.tDetailed.Ethernet.NET1.szIP = '0.0.0.0') OR (DG_NX3030.tDetailed
.Ethernet.NET2.szIP = '0.0.0.0')) THEN
//NIC Teaming enabled: error in two NETs to execute a switchover.
IF (DG_NX3030.tDetailed.Ethernet.NET1.bLinkDown AND DG_NX3030.tDetailed.Ethernet
.NET2.bLinkDown) THEN
//Change the local PLC to StandBy..
DG_NX4010.tRedundancy.RedCmdLoc.bStandbyLocal := TRUE;
END_IF
ELSE
//NIC Teaming disabled: error in one of NETs to execute a switchover.
IF (DG_NX3030.tDetailed.Ethernet.NET1.bLinkDown OR DG_NX3030.tDetailed.Ethernet.
NET2.bLinkDown) THEN
//Change the local PLC to StandBy.
DG_NX4010.tRedundancy.RedCmdLoc.bStandbyLocal := TRUE;
END_IF
END_IF
ATTENTION
When two Ethernet interfaces form a NIC Teaming pair, the inactive interface will always
have the IP address 0.0.0.0. This isn’t a valid IP and is no possible to configure manually an
interface with this address.
6.3.21. Fault Tolerance
The main objective of a redundant CPU is the system availability increase. The availability is the ratio between the time
while the system is working properly and the total time since the system has been implemented. For instance, if a system was
implemented 10 years ago and during this time, wasn’t working due to failures for a year, then its availability was only 90%.
This kind of availability is usually unacceptable for critic systems, where 99.99% availability is required, or even more.
In order to reach this availability level, several strategies are necessary:
Utilization of more reliable components (with high MTBF or Mean Time between Failures), contributing for the MTBF
increase of the system as a whole
Utilization of redundancy for, at least, the most critical components or components with smaller MTBF, in such a
way that a component failure can be tolerated without stopping the system. If the redundancy is implemented through
components duplication, it will be necessary that both fail for the system as a whole become unavailable
High diagnostics coverage, especially in redundant components. The component redundancy isn’t very useful for the
availability increase when is not possible to discover which component failed. In this case, the first failure in one
component still doesn’t drop the system, but remains hidden, until the second failure occurs, dropping the system,
as the first failure wasn’t yet repaired. The failures can be classified between diagnosable and hidden. It’s strongly
recommended that all redundant components failures are diagnosable
It’s also important that non-redundant components have wide diagnostics coverage, as, frequently, the system can con-
tinue working even with a non-redundant component failure. The component may not being requested, e.g. a relay with
NO contact which rarely has its coil activated, doesn’t have its failure detected until the moment the system requires its
closing
Low repair time for non-redundant components. A non-redundant component failure can drop the system, and during
the repair, the system will be unavailable
Possibility of repairing or substituting a redundant component without stopping the system. If this possibility exists, a
great availability increase it got. Otherwise, a stop must be programmed in order to substitute the component and the
repair time is computed as unavailable time
Low repair time for redundant components. A redundant component failure doesn’t drop the system, but during its
repair, a failure in its redundant pair could happen. For this reason, it’s important that the failure is repaired quickly after
diagnosed. The higher the repair time, the higher the probability of a second failure to occur in the redundant component
during this time, what would drop the system. Therefore, the higher the repair time, the lower the system availability
301
