2. TECHNICAL DESCRIPTION
2.2.7. Environmental Characteristics
NX3030
Current consumption on the power supply rail 1000 mA
Dissipation 5 W
Operating temperature 0 to 60
◦
C
Storage temperature -25 to 75
◦
C
Relative humidity 5% to 96%, non-condensing
Conformal coating Yes
IP Level IP 20
Module dimensions (W x H x D) 36,00 x 114,63 x 115,30 mm
Package dimensions (W x H x D) 44,00 x 122,00 x 147,00 mm
Weight 350 g
Weight with package 400 g
Table 15: Environmental Characteristics
Notes:
Conformal coating of electronic circuits: The covering of electronic circuits protects internal parts of the product against
moisture, dust and other harsh elements to electronic circuits.
2.3. Compatibility with Other Products
To develop an application for Nexto Series CPUs, it is necessary to check the version of MasterTool IEC XE. The following
table shows the minimum version required (where the controllers were introduced) and the respective firmware version at that
time:
Nexto Series CPUs MasterTool IEC XE Firmware version
NX3010, NX3020, NX3030 1.00 to 2.09 1.2.0.9 to 1.7.0.14
NX3010, NX3020, NX3030 3.00 or above 1.8.3.0 or above
Table 16: Compatibility with other products
Additionally, along the development roadmap of MasterTool IEC XE some features may be included (like special Function
Blocks, etc...), which can introduce a requirement of minimum firmware version. During the download of the application,
MasterTool IEC XE checks the firmware version installed on the controller and, if it does not meets the minimum requirement,
will show a message requesting to update. The latest firmware version can be downloaded from Altus website, and it is fully
compatible with previous applications.
2.4. Performance
The Nexto Series CPUs performance relies on:
User Application Time
Application Interval
Operational System Time
Module quantity (process data, input/output, among others)
15
