5. CONFIGURATION
Service TCP UDP
MasterTool MT8500 1217* 1740:1743
SQL Server 1433 -
MQTT 1883* / 8883* -
EtherNet/IP 44818 2222
IEC 60870-5-104 2404* -
OPC UA 4840 -
WEBVISU 8080 -
CODESYS ARTI 11740 -
PROFINET - 34964
Table 64: Reserved TCP/UDP ports
* Default port, but user changeable.
5.4. NX5000 Module Configuration
The NX5000 modules can be inserted in the project to increase the number of Ethernet interfaces if the local CPU interfaces
are not enough.
The Ethernet channels of the NX5000 modules can be used individually, or arranged in NIC Teaming pairs. NIC Teaming
pairs are used to provide redundant Ethernet channels. See availability in the Common General Features section.
An example of typical application for NX5000 module is the setting of a redundant HSDN (High Speed Deterministic
Network) for communication between different PLCs. Through this network, several PLCs can exchange messages in an
entirely segregated network to ensure determinism and fast communication. Moreover, setting up this network as redundant
with NIC Teaming pairs, provides an excellent availability. To build a redundant HSDN, two NX5000 modules must be
inserted. The figure below shows an example of redundant HSDN using two NX5000 modules.
The figure below also shows an example with one NX5000 module used isolated (without NIC Teaming redundancy),
inserted to the right of the other modules.
92
