5. CONFIGURATION

Internal -> IEC 60870-5-104 Analog

Internal Quality

Flags VALIDITY IEC 60870-5-104 Quality

FLAG_FILTER ANY -

FLAG_OVERFLOW ANY OVERFLOW

FLAG_REFERENCE_ERROR ANY INVALID

FLAG_INCONSISTENT ANY INVALID

FLAG_OUT_OF_RANGE ANY OVERFLOW

FLAG_INACCURATE ANY INVALID

FLAG_OLD_DATA ANY NOT TOPICAL

FLAG_FAILURE ANY INVALID

FLAG_OPERATOR_BLOCKED ANY BLOCKED

FLAG_TEST ANY -

ANY VALIDITY_INVALID INVALID

Table 52: Analog Points Conversion Internal to IEC 60870-5-104

Internal -> IEC 60870-5-104 Counters

Internal Quality

Flags VALIDITY IEC 60870-5-104 Quality

FLAG_RESTART ANY -

FLAG_COMM_FAIL ANY -

FLAG_REMOTE_SUBSTITUTED ANY -

FLAG_LOCAL_SUBSTITUTED ANY -

FLAG_FILTER ANY -

FLAG_OVERFLOW ANY OVERFLOW

FLAG_REFERENCE_ERROR ANY -

FLAG_INCONSISTENT ANY -

FLAG_OUT_OF_RANGE ANY -

FLAG_INACCURATE ANY -

FLAG_OLD_DATA ANY -

FLAG_FAILURE ANY INVALID

FLAG_OPERATOR_BLOCKED ANY -

FLAG_TEST ANY -

ANY VALIDITY_INVALID INVALID

Table 53: Counters Conversion Internal to IEC 60870-5-104

5.1.5.1.3. MODBUS Internal Quality

As the MODBUS standard don’t specify quality types to each point, but for help on use of each point’s communication

diagnostic, MasterTool allows the quality variables mapping, through an internal own structure, to each MODBUS point. The

table below describes the quality types that each MODBUS point can assume.

Resulting Quality Resulting VALIDITY Description

FLAG_RESTART VALIDITY_INVALID

Initial value. The point was

never updated.

- VALIDITY_GOOD

Communication OK. The

point is updated.
