ALTUS Nexto Series User Manual

2. TECHNICAL DESCRIPTION
2.7. Related Products
The following products must be purchased separately when necessary:
Code Description
MT8500 MasterTool IEC XE
AL-2600 RS-485 network branch and terminator
AL-2306 RS-485 cable for MODBUS or CAN network
AL-2319 RJ45-RJ45 Cable
AL-1729 RJ45-CMDB9 Cable
AL-1748 CMDB9-CFDB9 Cable
AL-1752 CMDB9-CMDB9 Cable
AL-1753 CMDB9-CMDB25 Cable
AL-1754 CMDB9-CFDB9 Cable
AL-1761 CMDB9-CMDB9 Cable
AL-1762 CMDB9-CMDB9 Cable
AL-1763 CMDB9-Terminal Block Cable
AL-1766 CFDB9-Terminal Block Cable
NX9101 32 GB microSD memory card with miniSD and SD adapters
NX9202 RJ45-RJ45 2 m Cable
NX9205 RJ45-RJ45 5 m Cable
NX9210 RJ45-RJ45 10 m Cable
NX9000 8-Slot Backplane Rack
NX9001 12-Slot Backplane Rack
NX9002 16-Slot Backplane Rack
NX9003 24-Slot Backplane Rack
NX8000 30 W 24 Vdc Power Supply Module
Table 19: Related Products
Notes:
MT8500: MasterTool IEC XE is available in four different versions: LITE, BASIC, PROFESSIONAL and ADVANCED.
For more details, please check MasterTool IEC XE User Manual - MU299609.
AL-2600: This module is used for branch and termination of RS-422/485 networks. For each network node, an AL-2600
is required. The AL-2600 that is at the ends of network must be configured with termination, except when there is a device
with active internal termination, the rest must be configured without termination.
AL-2306: Two shielded twisted pairs cable without connectors, used for networks based on RS-485 or CAN.
AL-2319: Two RJ45 connectors for programming the CPUs of the Nexto Series and Ethernet point-to-point with another
device with Ethernet interface communication.
AL-1729: RS-232C standard cable with one RJ45 connector and one DB9 male connector for communication between
CPUs of the Nexto Series and other Altus products of the DUO Series, Piccolo Series and Ponto Series.
AL-1748: RS-232C standard cable with one DB9 male connector and one DB9 female connector for communication
between CPUs of the Nexto Series and Altus products of the Cimrex Series.
AL-1752: RS-232C standard cable with two DB9 male connectors for communication between CPUs of the Nexto Series
and Altus products of the H Series and iX series.
AL-1753: RS-232C standard cable with one DB9 male connector and one DB25 male connector for communication
between CPUs of the Nexto Series and Altus products of the H Series.
AL-1754: RS-232C standard cable with one DB9 male connector and one DB9 female connector for communication
between CPUs of the Nexto Series and Altus products of the Exter Series or Serial port, RS-232C standard, of a microcomputer.
AL-1761: RS-232C standard cable with two DB9 male connectors for communication between Nexto Series CPUs and
Altus products of the AL Series.
18
