5. CONFIGURATION
1. Only one of the Scanners can establish an Exclusive Owner connection.
2. The same value of RPI(ms) must be configured for the Scanners.
The configuration data is defined in the EDS file. The data is transmitted to the remote adapter when the connection is
opened.
Configuration Description
Default
Value
Options
RPI (ms)
Request Packet Interval: ex-
change interval of the input
and output data.
10 ms
Multiple of MainTask inter-
val
O -> T Size (Bytes)
Size of the producer data
from the Scanner to the
Adapter (Originator -> Tar-
get)
Depends on adapter’s EDS 0 - 400
T -> O Size (Bytes)
Size of the consumer data
from the Adapter to the
Scanner (T -> O)
Depends on adapter’s EDS 0 - 400
Config #1 Size (Bytes) Size of configuration data 1. Depends on adapter’s EDS -
Config #2 Size (Bytes) Size of configuration data 2. Depends on adapter’s EDS -
Connection Path
Address of the configuration
objects - input objects - out-
put objects.
Depends on adapter’s EDS -
Table 139: EtherNet/IP Connection parameters
To add new connections there is the button Add Connection... which will open the New connection window. On this
window it’s possible to configure a new type of connection from the ones predefined on Adapter’s EDS or a generic connection
from zero.
193
