ALTUS Nexto Series User Manual

5. CONFIGURATION
Figure 124: IEC 60870-5-104 Server Mappings Screen
Parameter Description
Factory De-
fault
Possibilities
Value Variable Symbolic variable name -
Name of a variable declared
in a POU or GVL
Object Type
IEC 60870-5-104 object
type configuration
-
Single Point Information
Double Point Information
Step Position Information
Measured Value (Normal-
ized)
Measured Value (Scaled)
Measured Value (Short
Floating Point)
Integrated Totals
Single Command
Double Command
Regulating Step Command
Setting Point Command
(Normalized)
Setting Point Command
(Scaled)
Setting Point Command
(Short Floating Point)
Object Address
IEC 60870-5-104 mapping
first point’s index
- 1 to 65535
Size
Specifies the maximum data
quantity that an IEC 60870-
5-104 mapping will can ac-
cess
- 1 to 86400000
Range
Configured data address
range
- -
Counter Variable
Name of the symbolic vari-
able which will hold the
counter variable’s value
-
Name of a variable declared
in a POU, GVL or counter
module
Dead Band Variable
Name of the symbolic vari-
able which will hold the
dead band’s value
-
Name of a variable declared
in a POU or GVL
Dead Band Type
Defines the dead band type
to be used in the mapping
Disabled
Absolute
Disabled
Integrated
Select Required
Defines if it is required a
previous select to run a com-
mand
False
True
False
206
