2. TECHNICAL DESCRIPTION
NX3030
Electronic Tag on Display (ETD) Yes
Standards and Certifications
IEC 61131-3 Yes
DNV Type Approval – DNV-CG-0339
(TAA000013D)
Yes
IEC 61131-2 Yes
CE – 2014/35/EU (LVD) and
2014/30/EU (EMC)
Yes
RoHS – 2011/65/EU
Yes
UL Listed – UL61010-1 (file
E473496)
Yes
EAC – CU TR 004/2011 (LVD)
and CU TR 020/2011 (EMC)
Yes
Table 5: Common Features
Notes:
Real Time Clock (RTC): The retention time, time that the real time clock will continue to update the date and time after
a CPU power down, is 15 days for operation at 25
◦
C. At the maximum product temperature, the retention time is reduced to
10 days.
Maximum number of I/O modules on bus: The maximum number of I/O modules refers to the sum of all modules on
the local bus and expansions.
Event Log (SOE): Data types are found in the DNP3 Device Profile.
9
