5. CONFIGURATION
Condition
Enabled,
with Startup
Consistency
Enabled,
with Startup
Consistency
for Declared
Modules
Only
Enabled,
without
Startup
Consistency
Disabled
Disabled,
for declared
modules
only
Disabled,
without
Startup
Consistency
Non de-
clared
module
LED DG:
Blinks 2x
Application:
Run
LED DG:
Blinks 2x
Application:
Run
LED DG:
Blinks 2x
Application:
Run
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 2x
Application:
Run
LED DG:
Blinks 4x
Application:
Stop
Non de-
clared
module
(startup
condition)
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 2x
Application:
Run
LED DG:
Blinks 2x
Application:
Run
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 2x
Application:
Run
LED DG:
Blinks 2x
Application:
Run
Absent
module
LED DG:
Blinks 2x
Application:
Run
LED DG:
Blinks 2x
Application:
Run
LED DG:
Blinks 2x
Application:
Run
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 4x
Application:
Stop
Absent
module
(startup
condition)
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 2x
Application:
Run
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 2x
Application:
Run
Incompatible
configura-
tion
LED DG:
Blinks 2x
Application:
Run
LED DG:
Blinks 2x
Application:
Run
LED DG:
Blinks 2x
Application:
Run
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 4x
Application:
Stop
Incompatible
configura-
tion(startup
condition)
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 2x
Application:
Run
or
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 2x
Application:
Run
Duplicated
slot address
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 4x
Application:
Stop
Non-
operational
module
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 4x
Application:
Stop
LED DG:
Blinks 4x
Application:
Stop
Table 44: Hot Swap and Conditions Relations
Note:
Enabled, without startup consistency: When this hot-swap mode is configured, in normal situations when there’s an
incompatible module on the system’s startup, the application will go from Stop to Run. However, if that module is configured
as a NX5000 or a NX5001 and there’s a different module in that position, the application will stay in Stop.
